Industrial L2+ Managed 12-Port 1000X SFP + 2-Port 1000X SFP Fiber Switch

  • 1
  • 2
  • 3

Brand Name : E-link

Model Number : ETH-DIMC2012FM

Certification : ISO9001, CE, RoHS, FCC

Place of Origin : China

MOQ : 1pcs

Price : negotiation

Payment Terms : L/C, T/T, Western Union, MoneyGram, Paypal

Supply Ability : 1000pcs/month

Delivery Time : 5-12 working days

Packaging Details : Ethernet Switch Standard Export Package

Key word : Industrial Ethernet Switch

Operating Temperature : -40°C to 80°C

Input Power : 12~48VDC

Dimensions (WxDxH) : 149 x 114 x 50 mm

Casing : Aluminum Case

Mounting Options : DIN-Rail mount

Contact Now

Industrial L2+ Managed 12-Port 1000X SFP + 2-Port 1000X SFP Fiber Switch
Advantages
► Support 12x1000Base-X SFP + 2x1000Base-X SFP
► DIP Switch supports one-key VLAN, one-key Ring Management
► Support connecting USB-C port for easy management, without the need to access the RS232 serial port at all
► 10K Bytes Jumbo Frame
► IEEE 802.3az Energy Efficient Ethernet (EEE)
Technical Indexes

Ethernet
Standards:IEEE 802.3u 100BASE-TX/100BASE-FX
IEEE 802.3ab Gigabit 1000T
IEEE 802.3z Gigabit SX/LX
IEEE 802.3x flow control and back pressure
IEEE 802.3ad port trunk with LACP
IEEE 802.1D Spanning Tree Protocol
IEEE 802.1w Rapid Spanning Tree Protocol
IEEE 802.1s Multiple Spanning Tree Protocol
IEEE 802.1p Class of Service
IEEE 802.1Q VLAN tagging
IEEE 802.1X Port Authentication Network Control
IEEE 802.3u 100BASE-TX/100BASE-FX
Forward & Filtering Rate:148,800pps (100Mbps)
1,488,000pps (1000Mbps)
Packet Buffer Memory:12M bits
Processing Type:Store-and-Forward
Backplane bandwidth110Gbps
Max Packet Length:10K Bytes Jumbo Frame
Address Table Size:8K MAC Addresses

Overview
ETH-DIMC2012FM series is an Industrial 14 Port L2+ Managed Gigabit SFP Switch. It comprises of a 12-Port 100/1000Base-X SFP
fiber optic interface and 2 extra 1.25G SFP interfaces delivered in an IP40 case with redundant power system, being able to operate
under the temperature range from -40 to 80 Degree Celsius, the ETH-DIMC2012FM can be placed in virtually any environment. T
he ETH-DIMC2012FM provides advanced Layer 2 to Layer 4 data switching and redundancy, Quality of Service traffic control,
network access control and authentication, as well as Secure Management features to protect customer’s industrial and automation
network connectivity.
Industrial L2+ Managed 12-Port 1000X SFP + 2-Port 1000X SFP Fiber Switch
Ordering Information

ModelDescription
ETH-DIMC2012FMIndustrial L2+ Managed 12-Port 1000X SFP + 2-Port 1000X SFP Fiber Switch
SFP Options► SFP option. Please select your SFP on our SFP Options Page
► SFP module is to be purchased separately.
Mounting Options► Default DIN-Rail Bracket installed
Power Options► DIN-Rail Power Supply. Open Wire for Terminal Block.
► Power Supply is to be purchased separately.
